Compression action diagrams

The compression action diagram is primarily used to show ..

1. the relationship between the input and output levels of an audio signal passing through an audio compressor or limiter, expressed as the ratio
2. the level, or threshold at which compression is triggered
3. any non-linearities in the value of the ratio around the threshold caused by the electronic design of a compression device or controlled by a device's compression knee and attack controls

Now, click to watch our video at our sister site ..
